BOE MLED AM COG
The COG(Chip-On-Glass) AM Pitch0.9mm Mini LED, a display product self-developed by BOE, significantly improves the performance of display devices in many aspects such as picture quality, eye protection and power consumption, bringing more possibilities for professional display, performance events and other kinds of scenes.
BOE MLED AM COG
-
BOE MLED AM COG
-
BOE MLED AM COG
-
BOE MLED AM COG
-
4K COG Conference Room Project
BOE MLED COG AM P0.9 4K display project is used in the multifunctional conference room HD conference screen, ultra-high brightness, ultra-light color gamut, perfect image, healthy eye protection, to meet the user's needs in all aspects, presenting a full-scene immersive experience.
-
4K COG Conference Room Project
Product Highlights
Honor & Certification
Product Parameters
Contact us
Product Highlights
AM drive
Low blue light, flicker free, jitter free
-
High color performance and customized
>110%NTSC
-
Low power
At the same transmittance, AM reduces power consumption by 20% relative to PM and temperature by 4.4°
-
Glass based
High flatness, no splicing, thin and light
-
Ultra-high contrast ratio
1000000：1
Honor & Certification
TÜV Rheinland Low Blue Light & Hardware Solution Flicker Free
-
CES 2021 Innovative Display Application Product Award of the Year
-
SID 2022 Display Component of the Year
-
TÜV SÜD The World's First Visual Comfort Certification
-
CES 2021 Innovative Display Application Product Award of the Year
-
SID 2022 Display Component of the Year
-
TÜV SÜD The World's First Visual Comfort Certification
-
TÜV Rheinland Low Blue Light & Hardware Solution Flicker Free
-
CES 2021 Innovative Display Application Product Award of the Year
-
SID 2022 Display Component of the Year
-
TÜV SÜD The World's First Visual Comfort Certification
-
CES 2021 Innovative Display Application Product Award of the Year
Product Parameters
| BYH-COG | |
|---|---|
| Specifications | BYH-G009A0 |
| Pitch | 0.9375 |
| Module Resolution | 160*180 |
| Module Size (mm) | 150*168.75 |
| Cabinet Size (mm) | 600*337.5*47 |
| Pixel Density (dot/m²) | 1137777 |
| Flatness (mm) | ≤0.1 |
| Brightness（nit） | 1000（Peak）500（Typ） |
| Gamut | NTSC >110% |
| Driving Method | Active DC drive |
* Please click on the bottom of the project for more product details.
